Entone Technologies 00RC45P IR+RF Remote User Manual RAP 2nd stream kit v3

Entone Technologies (HK) Limited IR+RF Remote RAP 2nd stream kit v3

RC45P User Guide

Folio one v3

Entone RAP (Remote Antenna Packhistoric period) Installation Guide

The Entone RAP (Remote Antenna Package) contains a radio frequency URC (Universal Remote

Control) and a TRAM (Tv set Remote Antenna Module). By installing the Entone RAP, you can

control the Entone STB in a remote room and enjoy TV service from Entone STB anywhere in

your homdue east.

The Entone RAP contains the following components:

Entone RF URC Entone radio frequency URC (Universal Remote

Control)

two ten AA size batteries for the URC

TRAM TV Remote Antenna Module

1. TRAM Installation (in remote room)

Please follow the following diagram to install the TRAM. The TRAM is used to enhance the URC

radio frequency transmission using the Idiot box coax cable network in your domicile.

Plug the TRAM into the TV

coax network wall outlet.

Connect the TV coax cablevision

to the TRAM and the Television.

two. Connecting STB to the TV coax network

Connect the Entone STB to the TV coax network wall outlet according to whether you are using an

Entone Janus F1 or Amulet F1 STB.

2.1 Janus F1 Connection

Connect the Janus

F1 "MATV" output

to the TV coax

network as shown.

2.ii Amulet F1 Connection

Connect the Amulet

F1 "ANTENNA

OUTPUT" and

"COAX" output to

the TV coax network

every bit shown using a 3-

way splitter (which is

non provided).

Page 2 v3

iii. Remote Registration

You lot may need to register the Entone URC to the STB before you can use the URC. The URC

registration procedures may vary for unlike middleware and Television set service running in the Entone

STB. Please refer to the Goggle box service user guide for detailed URC registration procedures.

Beneath lists the general URC registration procedures (Notation: Refer to your TV service user guide

for exact URC registration procedures):

3.one First the URC registration in the Entone STB by the following procedure:

Press and agree the "OK" push button on the STB front end panel for v seconds until the

impact panel backlight is flashing. The STB is now in URC registration mode.

Annotation: If registration is non completed in 30 seconds, the touch on panel backlight

will stop flashing.

3.2 Outset the URC registration mode in the URC by the post-obit procedure:

Printing "STB" button once on the URC.

Press and hold the "STB" push button on the URC for v seconds until the "STB" button

backlight is on.

Press "STB" button once again. Both the "STB" and "AUX" button backlight volition

illuminate.

Printing "i" or "2" to register the URC to stream one or stream 2 (depending on the

middleware). Upon successful registration, the STB POWER indicator volition flash

once and the bear upon panel backlight will cease flashing.

Note:

This device complies with Part xv of the FCC Rules. Operation is subject to the following two

conditions: (1) this device may not cause harmful interference, and (2) this device must

accept any interference received, including interference that may cause undesired operation.

Changes or modifications not expressly canonical by the party responsible for compliance

could void the user's authority to operate thursdaydue east equipment
